January 18th, 2012
A single output PWMs is converted to high current push-pull circuit configuration using UC3706 dual output driver series is provide on below schematic. UC3706 is one of UC1706 dual output driver family which interface low-level control functions and such power MOSFET’s (a high power switching).

These UC1706, UC2706, and UC3706 implies three functions such as single-low-current digital input then activates a pair of high-current which can source to 1.5A each, an optional single-ended to push-pull conversion, and current imiting, automatic deadband control, and thermal shutdown protection. UC3706 High Current Push-Pull Output Circuit Diagram continued »
Tags: dual ouput driver, Schottky
Posted in MOSFET | No Comments »
January 10th, 2012
For applications such as post switcher regulator, battery operated equipment and local on-card regulation the herein LM2991 low dropout adjustable negative regulator is a key component. This LM2991 said to be a short-circuit proof which may enhance the reliability of overloaded for long periods.
The circuit diagram above shows LM2991 negative low dropout adjustable regulator. Cin 10uF required if the LM2991 regulator is located more than 6 inches from the power supply capacitors. Then, you’ll need Co 10uF aluminium electrolytic or 1 uF solid tantalum for stability purpose, according to its datasheet.
LM2991 Low Drop Regulator Typical Application Circuit Diagram and Datasheet continued »
Tags: adjustable regulator, LM2991
Posted in Power Supply | No Comments »
January 5th, 2012
A circuit covers MAX15022 DC stepdown regulator is provided in below diagram. It shows MAX15022 double buck with tracking and two additional LDOs since MAX15022 is a a dual-output, PWM, Step-Down DC-DC regulator with dual LDO controllers. According to the MAX 15022 datasheet, this device can be applied in applications such as multivoltage supplies, auto-multimedia, PoE IP Phones, RFID reader card and networking.
MAX15022 Double Buck Circuit Diagram and Datasheet continued »
Posted in Power IC | No Comments »
October 3rd, 2011
This post below will show you with a guide for making a low-cost temperature control kit with can also describe the using of microcontrollers in process automation, experimenting with digital PID controllers, and the use of Ziegler-Nichols tuning method.

The electrical circuit diagram of this temperature control circuit consists 3-pin analog temperature sensor (LM35DZ), a built-in A/D converter microcontroller (PIC16F877), and the heater driver (IRL1004).
Temperature Control Circuit Diagram using Microcontroller and Heater Driver continued »
Tags: LM35 datasheet, temperature control circuit, temperature control kit
Posted in Sensor | No Comments »
October 3rd, 2011
LM35 is one of integrated-circuit temperature sensors which can be applied easily as others. This device is sometimes soldered to a small light-weight heat fin, to decrease the thermal time constant and speed up the response in slowly-moving air, according to the datasheet.

As you can see, above circuit shows Temperature to Digital Converter diagram using this LM35 sensor with a bypass capacitor from VIN to ground and a series RC damper such as 75W in series with 0.2 or 1 uF from output to ground.
Temperature to Digital Converter Circuit Diagram using LM35 continued »
Tags: LM35 datasheet, Temperature Sensor
Posted in Sensor, Temperature | No Comments »
September 27th, 2011
This schematic diagram below shows you with LM139 series low power low offset voltage quad comparators. Including to the LM139 series, there are such LM239/LM339/LM2901/LM3302 which were designed specifically to operate from a single power supply over a wide range of voltages.

This LM139 device has advantages such as power drain suitable for battery operation, eliminates need for dual supplies, allows sensing near GND, compatible with all forms of logic, and known to be a high precision comparators.
LM139 Comparators Schematic Diagram and Datasheet continued »
Tags: LM139 datasheet, LM239 comparator, LM339 datasheet, Schematic Diagram
Posted in Power IC | No Comments »
